Adjustable Five-Point Safety Seat Belt

As a leading safety belt supplier in China, Chuanghecheng launches this adjustable five-point safety seat belt, which has achieved significant upgrades in the two major functions of emergency locking and quick release, providing all-round safety protection. This product is made of high-strength materials and features an extremely strong tensile strength and a quick escape design. It is suitable for various scenarios such as racing cars, go-karts and special vehicles.

Send Inquiry

Product Description

Product Introduction

China Chuanghecheng adjustable five-point safety seat belt is specially designed for high-intensity safety requirements. With dual upgraded functions of emergency locking and quick release, it firmly locks in the event of a collision and instantly releases in dangerous situations, providing reliable protection for drivers.

Product Characteristic

1. High safety performance

When a vehicle is involved in a collision or undergoes sudden deceleration, the seat belt automatically locks instantly, effectively restricting the body's displacement.

In case of emergency, the release device can be triggered with one hand, allowing for a quick escape within one second and buying crucial time for escape.

2. High-strength materials and structures

The core buckle of the seat belt is made of quenched automotive steel and CNC precision machined aluminum alloy to ensure that the components do not deform under extreme forces. The thickened shoulder strap with padding design reduces the pressure caused by long-term wearing, balancing safety and comfort.

3. Multi-scenario compatibility

The product is compatible with racing cars, go-karts, amusement equipment and special operation vehicles. It has standard installation interfaces and can be used directly without complex modifications.

4. Humanized detail design

Our adjustable five-point safety seat belt supports length adjustment to keep the interior clean and tidy.

The surface of the webbing has undergone special treatment, which makes it highly wear-resistant and has a long service life.

Core Parameters

Components	Technical Specifications
Core Fasteners	Automotive-grade steel with hardening treatment
Quick-Release Fasteners	High-strength aluminum alloy with CNC machining
Shoulder Strap System	Double shoulder straps with shoulder pads
Webbing Strength	Static tensile strength > 20,000N
Locking Mechanism	Emergency locking function
Surface Finish	Environmentally friendly chrome plating/powder coating

How to buckle a race five-point seat belt?

First, please sit properly, adjust your sitting posture, keep your body straight and close to the back of the chair.

Step 1 is to fasten the belt: Pull the left and right belts in front of the crotch and fasten the main button.

Step 2 is to connect the crotch strap: Pull the crotch strap up from between your legs, pass it through the main buckle and secure it to the belt.

Step 3 is to connect the shoulder straps: Pull the shoulder straps on both sides to your chest and fasten them with the main buttons.

Step 4: is to tighten the belt: Pull the belt tight with force to make it tightly wrap around the buttocks. This is the foundation of safety restraint.

Step 5 is to tighten the shoulder straps: Pull the shoulder straps tight to fit the shoulders and chest, and keep the corners of the straps facing the installation points below the body.

Finally, check and secure: Ensure that all webbing is flat, free of twist, and of appropriate tightness. Use webbing buckles or cable ties to store any excess shoulder straps to prevent them from dragging or falling.
